| Model |
AF-PS8 CS |
AF-PS10 CS |
AF-PS12 CS |
| CAPACITY |
|
| Length Of Cut (mm) |
2650 (Max) |
3250 (Max) |
3850 (Max) |
| Depth Of Cut (mm) |
80 (Max) |
80 (Max) |
80 (Max) |
| MAIN SAWBLADE |
|
| Main Blade Dim. (mm) |
ø355 |
ø355 |
ø355 |
| Arbor Dim. |
ø1" |
ø1" |
ø1" |
| Main Blade Arbor Speed (R.P.M) |
4800 |
4800 |
4800 |
| SCORING SAWBLADE |
|
|
|
| Blade Dim. (mm) |
ø180 |
ø180 |
ø180 |
| Arbor Dim. |
ø1" |
ø1" |
ø1" |
| Scoring Blade Arbor Speed (R.P.M) |
6500 |
6500 |
6500 |
| SAW CARRIAGE |
|
| Feed Forward Speed (M/min) |
9~37 |
9~37 |
9~37 |
| Retract Speed (M/min) |
67 |
67 |
67 |
| MOTOR |
|
|
|
| Main Sawblade Motor (Hp) |
15 |
15 |
15 |
| Saw Carriage Drive Motor (Hp) |
2 |
2 |
2 |
| High Pressure Blower Motor (Hp) |
3 |
3 |
3 |
| OTHERS |
|
| Automatic Feed System (Kw) |
1 (AC servo) |
1 (AC servo) |
1 (AC servo) |
| Automatic Panel Feed Speed (M/min) |
30 |
30 |
30 |
| Machine Dim. |
211"x220"x60" |
232"x244"x60" |
4800/5400 kgs |
| Packing Dim. |
20' container |
20' container |
40' container |
| Net / Gross Weight (kgs) |
4200/4700 |
4500/5100 |
4800/5400 |
| *All specifications, dimensions and design characteristics shown in this catalogue are subject to change without notice. |
